A variable frequency drive operates at 460 volts, 3-phase, 60 hertz and connects to a secondary pump designated HWP-S1. The control interface utilizes analog inputs, digital outputs for start and stop commands, digital inputs for alarms and status, and an analog output for speed and flow monitoring. A differential pressure sensor with high and low connection points provides additional analog input monitoring to the system.
VARIABLE FREQUENCY DRIVE START/STOP SPEED/FLOW STATUS ALARM DPS H L 460/3/60 SECONDARY PUMP HWP-S1 DI DO AO DI CSR AI AI
