A CoreBrace buckling-restrained brace connects to a steel column and base plate assembly supported by a concrete foundation. Stiffener plates are welded near side and far side as required by the manufacturer. A concrete block out is detailed adjacent to the structural steel base plate within the slab on grade. Anchor bolt and base plate information is referenced to a separate drawing.
WORK POINT CONCRETE FOUNDATION SEE 7/S602 FOR BASE PLATE AND ANCHOR BOLT INFORMATION Wb Lwb Wb Lwb CONCRETE BLOCK OUT STIFF PLATE NS & FS AS REQD BY COREBRACE, TYP SLAB ON GRADE Wc Lwc Wc Lwc Lgc Lgb NOTE: REFERENCE DETAIL 4 FOR ADDITIONAL INFORMATION. CoreBrace BRB, TYP
