A prefabricated roof curb is mounted to a typical composite metal deck with attachment detailed for concrete-filled metal deck. A 20-gauge sheet metal duct extends between five and seven feet, supported by a 20-gauge duct strap attached to the upper structure. A Ruskin CBD2 backdraft damper or equal is installed within the duct system, set at 0.01 inches water gauge static pressure to open. The underside features a 5/8-inch Type X gypsum board ceiling finish.
COMPOSITE DECK (TYPICAL) ATTACHMENT SEE #C-4/S1.33 FOR CONCRETE FILLED METAL DECK 1 OR EQUAL RUSKIN CBD2 BACKDRAFT DAMPER 5/8" TYPE 'X' GYPSUM BOARD FULLY EXTENDED MINIMUM 5 FT., MAXIMUM 7 FT. 20 GAUGE SHEET METAL DUCT PREFABRICATED CURB SET AT 0.01" W.G.S.P. TO OPEN PROVIDE 20 GA. DUCT STRAP, SEE STRUCTURAL DETAIL #2/S1.34 FOR UPPER ATTACHMENT.
