An HVAC diffuser or grille connects to a supply duct featuring a one-inch acoustical insulation liner and a flexible connection not to exceed five feet in length. The flexible duct diameter matches the diffuser or grille duct diameter plus two inches. The entire assembly integrates directly into a T-bar ceiling grid.
5 FEET IN LENGTH 1" ACOUSTICAL INSULATION LINER FLEX CONNECTION - NOT TO EXCEED DIFFUSER OR GRILLE DUCT DIA. PLUS 2" T-BAR CEILING GRID
