The supply duct static pressure sensor is located seventy percent down the longest duct run, equipped with a differential pressure transmitter. The exhaust air duct incorporates an airflow measuring station and a motorized normally open return air damper. These components provide necessary control inputs for mechanical air distribution and balancing.
EXHAUST AIR DPT H L AFMS M N.O. SUPPLY AIR LOCATE SENSOR 70% DOWN LONGEST DUCT RUN SUPPLY DUCT STATIC PRESSURE RETURN AIRFLOW RETURN AIR DAMPER
