A maximum 24-inch by 24-inch galvanized steel duct penetrates a one- or two-hour rated gypsum wallboard assembly conforming to U.L. U400 or V400. An annular space surrounds the duct, sealed with a minimum 1/4-inch bead of SSS or LCI sealant on one side and a minimum 5/8-inch bead of LCI sealant on the other. The penetration complies with STI System Number W-L-7029 for firestopping.
0" MIN. ANNULAR MINIMUM 1/4" BEAD OF SSS OR LCI SEALANT NO. 26 GAUGE (OR HEAVIER) GALV. DUCT 1 OR 2 HR FIRESTOP FOR 24"x24" (MAX.) THROUGH A GYPSUM WALLBOARD ASSEMBLY GALV. STEEL DUCT STI # W-L-7029 MAX. 24"x24" SPACE. MINIMUM 5/8" BEAD OF LCI SEALANT PER U.L. U400 OR V400. WALLBOARD ASSEMBLY. 1 0R 2 HOUR GYPSUM SPACE. 2" MAX. ANNULAR
