A custom stainless steel manifold enclosure features a lockable, hinged access panel and maximum dimensions of 42 inches wide by 24 inches tall by 8 inches deep. The enclosure is mounted at 12 inches above the finished floor on the wall. Hot water supply and hot water return tubing run from the manifold to the forum slab above, protected by a custom shroud matching the enclosure. Additional piping routes to RWHX-1.
CUSTOM STAINLESS STEEL MANIFOLD ENCLOSURE WITH LOCKABLE, HINGED ACCESS PANEL. ALL MANIFOLD PROTECT TUBING WITH CUSTOM SHROUD TO MATCH CUSTOM ENCLOSURE. FLOOR COMPONENTS SHALL FIT WITHIN ENCLOSURE. MAXIMUM DIMENSIONS SHALL BE 42" WIDE X 24" TALL X 8" DEEP. MOUNT AT 12" ABOVE FINISHED FLOOR. HWS & HWR TUBING FROM MANIFOLD TO FORUM SLAB ABOVE. ROUTE TO RWHX-1 WALL
