Hot water supply and hot water return lines drop down within the wall to connect to a baseboard radiation finned element housed inside a continuous enclosure. The piping assembly incorporates typical shut-off valves, unions, reducers, a strainer, and an automatic control valve. The hot water return line remains uninsulated inside the enclosure, while end insulation is provided at the enclosure termination. The entire assembly maintains an 8-inch clearance to the floor.
HWR LINE UNINSULATED INSIDE ENCLOSURE FINNED ELEMENT SEE SCHEDULE FOR LENGTH REDUCER (TYPICAL) UNION (TYPICAL) AUTO CONTROL VALVE STRAINER 8" TO FLOOR END INSULATION AT ENCLOSURE SHUT OFF VALVE (TYPICAL) ENCLOSURE SEE SCHEDULE AND PLAN FOR LENGTH AND CONFIGURATION DROP IN WALL HWR HWS
