Three-dimensional ductwork arrangement diagram shows dimensional sizing for exhaust fan sections EF-302, EF-304, and EF-305. The assembly includes specific horizontal and vertical lengths indicated by 52-inch, 20-inch, and 36-inch dimensions. Accompanying general notes reference the specific exhaust fan designations.
SECTION FOR EF-302 EXHAUST. SECTION FOR EF-304 EXHAUST. SECTION FOR EF-305 EXHAUST. NOTES: 1. 2. 3. 1 52" 20" 36" 20" 2 3
