An acoustically lined sheet metal return air collar extends out fourteen inches minimum and opens directly to the return air plenum. Two sheet metal band hangers suspend the assembly from above. A six-inch minimum clearance is maintained above the finished ceiling where the collar connects to the full-size ceiling return grille.
SHEET METAL RETURN AIR COLLAR - ACOUSTICALLY LINED. FULL SIZE OFF RETURN REGISTER. FINISHED CEILING CEILING RETURN GRILLE SUSPEND FROM ABOVE- SHEET METAL BAND HANGER (2 REQUIRED) 14" MIN. 6" MIN. SHEET METAL RETURN AIR COLLAR EXTENDING OUT 14" MIN. AND OPEN TO RETURN AIR PLENUM.
