A roof-mounted exhaust fan is secured to a prefabricated roof curb with spring vibration isolators and seismic snubbers featuring an integral weather cover. The exhaust fan assembly connects to supply, return, and outside air ducts via flexible connections and bolted, gasketed galvanized iron joints. A 20-gauge galvanized iron curb cap and flashing provide weatherproofing at the roof penetration, while guy wires stabilize the stack which incorporates a 45-degree discharge and a stainless steel birdscreen attached with bent-down tabs and stainless steel bolts. Chilled water and hot water coils connect within the ductwork, supported by a condensate drain line sloped at 1/8 inch per foot and suspended with steel all-thread rods and spring vibration isolators anchored to the structure.
FLEXIBLE CONNECTION (4) 3/8" STEEL ALL-THREAD RODS WITH SPRING VIBRATION ISOLATORS, ANCHORED TO STRUCTURE AS REQUIRED. FLEXIBLE CONNECTION RETURN AIR SUPPLY AIR DUCT. SEE PLANS FOR SIZE. TRANSITION FROM UNIT SIZE AS REQUIRED. CHILLED WATER COIL. SEE COOLING COIL PIPING 3- WAY CONNECTIONS DETAIL. 3/4" CONDENSATE DRAIN LINE. SLOPE AT 1/8" PER FT. CHILLED WATER PIPING SEE PLANS. HOT WATER COIL. (PIPING SIMILAR TO CHILLED) OUTSIDE AIR CURB PREFAB ROOF THYCURB AS SHOWN ORIENT OPENING GUY WIRE (TYP.) SPRING ISOLATORS SEISMIC SNUBBERS WITH INTEGRAL WEATHER COVER FAN TO CURB SECURE EXHAUST THRU ISOLATORS DRAIN 20 GA. G.I. CURB CAP FLEXIBLE CONNECTION 20 GA. G.I. FLASHING JOINTS TO BE BOLTED AND BACK DRAFT DAMPER AND 1/4" STAINLESS STEEL BOLTS ATTACHED WITH 4 BENT DOWN TABS 1/2" x 1/2" 16 GA. SS BIRDSCREEN GASKETED. 45° FLEXIBLE CONNECTION ROOF 10'-0" MIN. SCALE: NTS 7 ROOF MOUNTED EXHAUST FAN DETAIL
