Ceiling-hung equipment is suspended using threaded support rods equipped with rod stiffeners and diagonal cable braces. Transverse and longitudinal cable braces extend from the support members at an angle between thirty and ninety degrees. Support rods feature a forty-five degree angle requirement for bracing stability. Cable connections tie the suspended unit to the overhead structural system.
TRANSVERSE and LONGITUDINAL (4-WAY) BRACE FOR CEILING HUNG EQUIPMENT PLAN VIEW CEILING HUNG EQUIPMENT CEILING HUNG EQUIPMENT SUPPORT ROD (SHOWN) WITH ROD STIFFENER. SEE ROD 45° REQUIREMENTS. STIFFENER DETAILS FOR TRANSVERSE & LONGITUDINAL (TYP.) CABLE BRACE SUPPORT MEMBER SUPPORT MEMBER 30° - 90° SEE DETAILS OF TYPICAL CABLE CONNECTIONS TO SEE DETAILS OF TYPICAL CABLE CONNECTIONS TO BRACED COMPONENTS STRUCTURE
