A sheet metal branch duct connects to a main rectangular duct using a conical tap set at a forty-five degree angle. A locking quadrant volume damper is installed in the branch duct at a minimum distance of one-third the duct width, or six inches minimum. The branch round duct transitions from the main supply or return duct as specified.
RETURN/EXHAUST AIR FLOW AIR FLOW SUPPLY 45° W D FLOW AIR SHEET METAL DUCT AS SPECIFIED LOCKING QUADRANT VOLUME DAMPER 1/3W, 6" MINIMUM CONICAL TAP MAIN DUCT 1 1 2 3 4 5 2 3 4 5 1 2 3 4 5 6 12 9 11 13 RECTANGULAR DUCT TAKEOFF N.T.S. 03 RECTANGULAR TO ROUND DUCT TAKEOFF
