A plate and frame heat exchanger is mounted on a concrete housekeeping pad and connected to load and source piping networks. Pressure gauges and quarter-inch tubing lines route to the atmosphere and floor drains. Pressure relief valves are set to fifteen psi below the rated operating pressure of the heat exchanger.
MAV MAV HOUSEKEEPING PAD DV DV TO FLOOR DRAIN (TYP) LOAD SOURCE PRESSURE GAUGE (TYP) 1/4 INCH TUBING (TYP) TO ATMOSPHERE (TYP) HEAT EXCHANGER A. SET PRESSURE RELIEF VALVES TO 15 PSI BELOW THE RATED OPERATING PRESSURE OF THE HEAT EXCHANGER. GENERAL NOTES: TO FLOOR DRAIN (TYP) NONE 7 PLATE AND FRAME HEAT EXCHANGER PIPING
