FCU Piping Connection with 3-Way Valve

Materials

Elements

Insulation Drainage Connections / Plates

About this detail

The supply and return piping connects to the fan coil unit through a minimum of twenty-four-inch stainless steel braided flexible hoses. The supply line includes a shutoff ball valve with a pressure-temperature test plug, a Y-strainer equipped with a drain valve, pressure-temperature test plug, and cap with chain, followed by a cartridge-type flow setter. The return line features a static balancing circuit setter, a three-way control valve with a bypass loop, and a manual air vent. A condensate drain line routes away from the primary drain pan.
