An existing steam pipe routes through a concrete slab penetration with surrounding structural sleeve framing. Existing eight-inch BSCF members provide support with a height dimension of four feet six inches. Existing grooved joints connect the vertical pipe segments adjacent to the slab. The installation integrates with the existing mechanical room infrastructure.
EXISTING 8“ BSCF (TYP 2) 0 F9 T PIPE EXISTING STEAM PIPE * EXISTING 8" BSCF (TYP 2) 0 v‘i . CM Q- >- +1 CO M- \ s A SLAB PENETRATION EXISTING GROOVED JOINT
