About this detail

Galvanized iron duct interiors receive an internal duct liner adhered with one hundred percent Miracle PF96 adhesive. Mechanical fasteners such as Omark Insul-Pins, Dura Dyne fasteners, or Grip Nails are installed using a Grip Nail air hammer or automatic fastener equipment at a maximum spacing of twelve inches on center. Fasteners are placed not more than two inches from the edge of the liner. All ends of the liner are coated with Miracle PF96 adhesive and butted firmly together, with top and bottom sections overlapping the sides. A separate high-pressure rated factory-made round duct connects to a supply air diffuser at the ceiling using a binding strap and mastic.
