Acoustic and thermal duct liner is adhered to the interior of a galvanized iron duct using a one hundred percent coverage adhesive such as Miracle PF 96. The top and bottom sections of the liner overlap the sides, with the ends of the liner coated in adhesive not more than two inches from the edge and butted firmly together. Metal fasteners including Omark Insul-Pins, Duro Dyne fasteners, or Grip Nails are installed at a maximum spacing of twelve inches center-to-center using a pneumatic air hammer or automatic fastener equipment. All supply air ducts are wrapped externally per specifications.
DUCT LINER GALV. IRON DUCT TOP AND BOTTOM SECTION OF LINER SHALL OVERLAP THE SIDES LINER TO BE ADHERED TO DUCT WITH 100% ADHESIVE (MIRACLE PF 96) ENDS OF LINER TO BE COATED WITH ADHESIVE. (MIRACLE PF 96) NOT MORE THAN 2" FROM EDGE OF LINER ENDS OF LINER SHALL BE BUTTED FIRMLY TOGETHER NOTE: ALL SUPPLY AIR DUCTS SHALL BE WRAPPED EXTERNALLY AS PER SPECIFICATIONS. METAL FASTENERS: OMARK INSUL-PINS, DURO DYNE FASTENERS OR GRIP NAILS. GRIP NAILS SHALL BE INSTALLED BY "GRIPNAIL AIR HAMMER" OR BY "AUTOMATIC FASTENER EQUIPMENT". 12" C.C. MAX. (TYP.) 2"
