Suspended equipment support framing utilizes diagonal bracing on four sides to stabilize mechanical units. Support framing connects to the overhead structure via anchor bolts. Rod bracing or diagonal braces are installed on four sides or four corners with alternate location options for seismic or lateral restraint.
SUSPENDED EQUIPMENT DIAGONAL BRACE TYP. 4 SIDES EQUIPMENT SUPPORT FRAMING ALTERNATE LOCATION OF BRACE, TYP. 4 CORNERS ANCHOR BOLT TYP. EQUIPMENT ROD BRACING, TYP. 4 SIDES
