A return air grille connects to a full-size lined duct that transitions to a full width and half height configuration, maintaining a minimum height of six inches. The duct connection to the grille is sealed airtight. The boot extends a minimum of six inches above the grille and twelve inches past the grille, and the entire assembly is supported from the structure above.
THIS DUCT SHALL BE FULL WIDTH, AND HALF HEIGHT. HEIGHT SHALL BE NO LESS THAN 6" FULL SIZE LINED DUCT SEAL AIR TIGHT AT DUCT CONNECTION TO GRILLE CEILING RETURN AIR GRILLE EXTEND BOOT A MINIMUM OF 6" ABOVE GRILLE AND 12" PAST GRILLE SUPPORT FROM STRUCTURE ABOVE
