Mechanical · M-PZER3

Sprinkler Arm-Over Detail

Units: imperial
Sheet: M302
Discipline: Mechanical

Materials

Metal (misc.)

Elements

Ceilings

Text on the drawing

CEILING SPRINKLER ARM-OVER PIPING SPRINKLER BRANCH OR CROSS MAIN 1" X 1/2" REDUCER CONCEALED SPRINKLER IN CENTER OF CEILING TILE.
