An isometric and cross-sectional detail showing support hanger spacing and fastening details for mechanical ductwork. The installation features a maximum center line spacing of sixteen inches, with three-inch edge clearances for attachment points. Mechanical fasteners secure the hanging assembly directly to the structural substrate. Numbered callouts reference specific components of the support bracket and fastening hardware assembly.
