A trapeze hanger assembly supports suspended mechanical services from overhead building structure. Threaded rods or straps attach directly to the primary structure and remain isolated from the roof deck. Bolts are sized according to the imposed load. Additional details show strap and angle configurations with beam clamps.
SLING TO AVOID DISRUPTION OF STRAP (TYP) SIZE BOLTS FOR LOAD ROD, ATTACH TO STRUCTURE NOT TO ROOF DECK (TYP) STRAP OR ANGLE TRAPEZE HANGERS
