A flexible duct connects to a ceiling diffuser set within the ceiling plane, with duct sizes specified per the plans. The flexible duct is limited to a maximum length of five feet and secures to the collar using two nylon duct straps. A one-inch by twenty-two gauge hanger band is fastened to the metal roof deck and concrete deck using screws to support the duct run. A minimum of two seismic straps are provided for lateral restraint.
FLEX DUCT, 5'-0" MAXIMUM LENGTH CONNECT FLEXIBLE DUCT TO COLLAR WITH (2) NYLON DUCT STRAPS PROVIDE (2) SEISMIC STRAPS MIN. CEILING ROOF DECK 1"x22 GAGE BAND SCREWS FLEXIBLE DUCT, SEE PLANS FOR SIZES CEILING DIFFUSER, SEE PLANS AND SCHEDULE CONCRETE DECK,
