A vertical pipe support is welded to an elbow carrying a pipe of size A, anchored to a concrete floor slab with a square base plate and expansion bolt anchors. The vertical pipe support size B is welded to the pipe elbow with a continuous weld. The base plate rests on a three-quarter-inch leveling grout layer over a concrete floor slab having a minimum strength of 3500 psi. Expansion bolt anchors secure the base plate, with specific sizes and dimensions provided in the accompanying sizing table for varying pipe diameters up to thirty inches.
PIPE SIZE "A" CENTERLINE OF PIPE 3/8 1/2 x 9 x 9 3 6 "A" 8 10 12 14 16 18 20 30 8 6 6 4 4 4 4 3 "B" "D" 3/8 1/2 1/2 3/4 "C" 1/2 x 9 x 9 3/4 x 10 x 10 3/4 x 10 x 10 3/4 x 10 x 10 3/4 x 10 x 10 7/8 x 12 x 12 7/8 x 12 x 12 7/8 x 14 x 14 1/2 1/2 1/2 1/2 BASE PLATE 1-1/2" 1-1/2" CONTINUOUS WELD 24 6 7/8 x 12 x 12 1/2 "C" 3'-0" MAX. EXPANSION BOLT ANCHOR "D" PIPE SUPPORT SIZE "B" BASE PLATE SIZE "C" 3/4" LEVELING GROUT NOTES: (1) ALL DIMENSIONS IN INCHES. (2) CONCRETE FLOOR SLAB TO HAVE MIN. 3500 PSI. (3) SUPPORT PIPE TO BE ASME A53, GRADE B, TYPE E OR S, STANDARD WEIGHT, CARBON STEEL. MAX WEIGHT (LB.) 780 1240 4940 5890 13000 2200 2800 3300 4000 8010
