Fabric duct sections are suspended using a dual track system with three and nine o'clock attachment configurations. A safejoint component joins track lengths together, while snap-on suspension sections with cable droppers provide vertical support. One-inch nozzles by KE Fibertec are integrated into the fabric duct system.
ar^i=qo^`h=prpmbkpflk=abq^fi clo=c^_of`=ar`qp EP=^ka=V=lD=`il`h=^qq^`ejbkqF SNAP ON SUSPENSION SECTION KE DIREJET (1" NOZZLES) BY KE FIBERTEC SAFEJOINT FOR JOINING TRACK WITH CABLE DROPPER
