Dual inline pumps mount on a field-fabricated support stand anchored to the floor slab. Piping configurations require a minimum of five pipe diameters of straight pipe upstream of the check valve or per the manufacturer's recommendation. System high points and necessary locations feature automatic air vents to remove trapped air. A low point hose drain is provided for system maintenance and drainage.
SEE PLANS FOR PIPE SIZES PROVIDE A MINIMUM OF 5 PIPE DIAMETERS STRAIGHT PIPE UPSTREAM OF CHECK VALVE OR PER MANUFACTURER'S RECOMMENDATION 1. SUPPORT PUMP FROM ADJACENT PIPING. LOW POINT HOSE DRAIN AUTO AIR VENT AT SYSTEM HIGH POINTS AND WHERE NECESSARY TO REMOVE AIR FROM SYSTEM FLOOR FIELD FABRICATED SUPPORT STAND NOTES:
