A rooftop utility fan mounts on spring isolators or rubber grommets positioned over a concrete pad or sleepers installed by the general contractor. A flexible connection joins the fan unit to the main ductwork to absorb vibration and movement. A duct stack extends upward on the discharge side, while roof flashing and roofing materials are provided by others.
CONCRETE PAD OR SLEEPERS BY G.C, AS SHOWN ON PLANS SPRING ISOLATORS OR RUBBER GROMMETS AS INDICATED ON EQUIPMENT SCHEDULE AND VIBRATION ISOLATION SUBMITTAL ROOF ROOFING BY OTHERS FLEX CONNECTION DUCT DUCT STACK ON DISCHARGE DRAIN
