The cooling coil assembly connects to chilled water supply and return lines utilizing union or grooved joint couplings. The piping configuration includes an automatic 3-way valve, flow setter, calibrated balance valves, strainers, thermometers, and manual air vents designated as MAV. A drain valve with a provided threaded hose end and a full-size drain connects to the manufacturer's drain pan.
MANUAL AIR VENT THERMOMETER - O°/100° AUTOMATIC 3-WAY VALVE CHR CHS N.O. N.O. N.O. UNION OR GROOVED JOINT COUPLING STRAINER FLOW SETTER MAV MAV FULL SIZE DRAIN DRAIN VALVE. PROVIDED THREADED HOSE END. MANUFACTURER'S DRAIN PAN. CALIBRATED BALANCE VALVE.
