Self-regulating heat tracing runs along the outdoor water piping, secured with glass cloth adhesive tape and terminated with end seals. A power connection kit supplies power to the heating cable. A tee and a valve are integrated into the piping run, with thermal insulation wrapped over the assembly to prevent freezing.
HEATER LOOP END SEAL POWER CONNECTION KIT SELF-REGULATING HEAT TRACING TEE THERMAL INSULATION END SEAL GLASS CLOTH ADHESIVE TAPE NOTES: PROVIDE HEAT TRACE FOR ALL WATER PIPING LOCATED OUTDOORS INSULATE THE PIPING. 1. 2.
