This plan view shows a fan coil unit connected to a duct transition and a filter box housing a MERV-13 filter. An outside air duct ties into the assembly near a hinged motorized volume damper and a wire mesh screen on the filter box. The hinged access allows for easy opening to facilitate filter replacement.
PLAN VIEW FAN COIL UNIT FILTER ACCESS FILTER BOX WITH MERV-13 FILTER OSA DUCT HINGED MVD & WIRE MESH SCREEN ON FILTER BOX, SHALL BE EASILY OPENED TO FACILITATE FILTER REPLACEMENT DUCT TRANSITION
