Typical Single Pipe Hangers

Materials

About this detail

Suspended piping is supported by a threaded hanger rod attached to the overhead structure according to specifications. Vibration isolators are included as required by project specifications. For pipes three inches outside diameter and smaller, a strap hanger supports the line. For pipes four inches outside diameter and larger, a clevis hanger is utilized. Insulated pipes include a protective pipe shield and a pipe saddle or blocking per specifications.
