Hydronic heating water supply and return piping connects to a circulating pump and a mixing valve. The main loop feeds multiple radiant heating zones through zone headers, each equipped with a loop shut-off valve, two-way zone control valve, and a circuit setter. Each heating zone includes embedded radiant piping loops paired with a slab temperature sensor.
HHWS HHWP 2 HHWR CIRCUIT SETTER (TYP) MIXING VALVE (E) HHWS&R, REFER TO DETAIL 5 THIS SHEET 2-WAY ZONE CONTROL VALVE (TYP) LOOP SHUT-OFF VALVE (TYP) ZONE HEADER (TYP) ZONE A ZONE B ZONE C ZONE D ZONE F ZONE E ZONE G HV-1 HV-2 REFER TO DETAIL 8 THIS SHEET FOR PIPING SCHEMATIC (TYP 2) HHWR HHWR S SLAB TEMPERATURE SENSOR (TYP 1 PER ZONE) S S S S S S T T CO2
