The exhaust duct connects directly to the top of the fume hood and matches the venturi valve neck size unless noted otherwise on the plan. A debris screen is installed at the duct connection to the fume hood. A sound attenuator is positioned upstream of each venturi exhaust valve.
HOOD FLOOR CEILING EXHAUST DUCT TO BE SAME SIZE AS VENTURI VALVE NECK SIZE VENTURI VALVE UNLESS LABELED OTHERWISE ON PLAN REFER TO LAB DRAWINGS FOR FUME HOOD CONNECTION SIZE. PROVIDE TRANSITION. PROVIDE DEBRIS SCREEN AT DUCT CONNECTION TO FUME HOOD. SOUND ATTENUATOR UPSTREAM OF EACH VENTURI EXHAUST VALVE.
