The piping arrangement connects to the cooling or heating coil using a three-way modulating control valve paired with a calibrated balancing valve. Isolation valves and a strainer are installed on the main line to protect and service the equipment. Pressure and temperature test plugs are positioned alongside unions for maintenance access, and a three-quarter-inch ball valve with a hose thread provides a drain connection. An air vent is located at the high point of the piping, and all components are arranged to maintain required service clearances.
A CALIBRATED UNION, TYP. COIL STRAINER 3-WAY MODULATING CONTROL VALVE 3/4" BALL VALVE WITH HOSE THREAD DRAIN CONNECTION ARRANGE PIPING TO MAINTAIN REQUIRED SERVICE CLEARANCE ISOLATION VALVE BALANCING VALVE PLUG, TYP. P & T TEST NO NC AIR VENT AT HIGH POINT
