An insulated or uninsulated pipe penetrates a concrete floor slab through a pipe sleeve secured with a minimum of three poured-in-place anchor bolts. The annular space between the sleeve and the pipe is sealed with backing material as required and finished with sealant on both sides. A vapor barrier is incorporated into the insulated assembly, and a riser clamp is provided where applicable.
2" PIPE PIPE INSULATION SEALANT SEALANT PIPE SLEEVE WITH MIN 3 ANCHOR BOLTS POURED IN PLACE BACKING MATERIAL AS REQUIRED VAPOR BARRIER SEALANT SEALANT (TYP) RISER CLAMP WHERE APPLICABLE PIPE PIPE SLEEVE WITH MIN 3 ANCHOR BOLTS POURED IN PLACE BACKING MATERIAL AS REQUIRED 2" WITH PIPE INSULATION A
