A square neck T-bar ceiling diffuser is set within an acoustical ceiling grid and connected to a supply branch duct. The assembly utilizes a flexible duct with a maximum length of four feet, attached via a spin-in fitting equipped with a volume damper. The diffuser collar features an alternate location option and is lined internally with one-inch black acoustical liner.
LOCATION ALTERNATE COLLAR SIZE +3" 1" BLACK ACOUSTICAL LINER FLEX. DUCT (4' MAX LENGTH) SPIN-IN FITTING W/ VOLUME DAMPER SUPPLY BRANCH CEILING 4'-0" MAX. LENGTH NONE 5 TYPICAL SQUARE NECK T-BAR DIFFUSER
