The fan coil unit connects to a stud wall using a manufacturer mounting plate secured with one upper and one lower lag bolt or screw attachment per stud location. The unit clips directly into the manufacturer mounting plate typically. A note indicates that the detail is for reference only and that actual support design requires deferred approval with shop drawings and structural calculations by a licensed structural engineer for seismic and general support connections.
MANUFACTURER MOUNTING PLATE FCU SIDE VIEW LAG BOLT/SCREW (1)UPPER ATTACHMENT LAG BOLT/SCREW (TYP.5) PLAN VIEW STUD WALL LAG BOLT/SCREW (1)LOWER ATTACHMENT (1)UPPER ATTACHMENT LAG BOLT/SCREW (1)LOWER ATTACHMENT (1)UPPER ATTACHMENT MANUFACTURER MOUNTING PLATE FCU CLIPS INTO MANUFACTURER MOUNTING PLATE TYP. STUD WALL DETAIL IS PROVIDED AS REFERENCE ONLY. ACTUAL SUPPORT DESIGN WILL BE VERIFIED THROUGH THE SUBMITTAL PROCESS AS A DEFERRED APPROVAL. CONTRACTOR TO PROVIDE SHOP DRAWINGS AND STRUCTURAL CALCULATIONS BY A LICENSED STRUCTURAL ENGINEER FOR SEISMIC AND GENERAL SUPPORT CONNECTION TO STRUCTURE.
