Mechanical · M-J54XH

Deck Alignment / Bearing

Materials

weld

Elements

Beams Decks

Connections

Welded Connection Deck Attachment

About this detail

The steel deck runs parallel and completely bears on the top flange of the supporting steel beam. Puddle welds secure the deck to the beam flange per detail 9/S600.

PUDDLE WELDS PER DETAIL 9/S600 DECK TO COMPLETELY BEAR ON BEAM DECK PARALLEL B DECK PERPENDICULAR C DECK PARALLEL
