An electric wall heater is recessed into a wall cavity via a wall insert or can secured directly to the framing and concealed conduit. The unit features a sheath-type heater element and a self-contained thermostat with front and wall trim finishing the face. A minimum clearance of twelve inches is maintained from the bottom of the heater to the finished floor.
FRONT AND WALL TRIM SHEATH TYPE HEATER ELEMENT SELF-CONTAINED THERMOSTAT T CONDUIT WALL AND CONCEALED ELECTRIC WALL HEATER (SECURE TO WALL AND CONDUIT) CAN OR WALL INSERT TO FLOOR 12" MIN.
