A round spiral duct is suspended overhead by typical threaded rod duct hangers connected at the top. Two supply grilles with volume dampers branch off symmetrically via thirty-degree beveled takeoffs. All exposed joints are sealed with silicone sealer. General notes require referencing plans and specifications for balancing damper locations and note that ductwork, skirt, and supports are painted per architectural requirements.
