An overhead concrete slab anchors a suspended steel drop assembly using five-eighths inch diameter Hilti KB-TZ expansion anchors with a four-inch minimum effective embedment. The vertical hanger drop connects to a lower offset bracket secured with typical quarter-inch fillet welds. A horizontal support member spans outward with a maximum eighteen-inch drop dimension. Five three-quarter inch diameter anchor bolts secure the base plate configuration.
SECTION A-A A MAX. 18" A A 12" A 5/8" DIA. HILTI KB-TZ EXPANSION ANCHOR W/ 4.0" EFFECTIVE EMBEDMENT MIN. 4" 8" 5" (5) 3/4" DIA. TYP. 1/4" 1
