Branch ductwork connects to the main supply and return ducts at a forty-five-degree angle with a cinch collar lock on the upstream side. Main duct take-offs include a volume damper when there are no future branch take-offs. Branch dimensions follow the formula length equals width divided by four, with a four-inch minimum. Additional volume dampers are provided in the branch ductwork per volume damper details and duct sizes are sized per plans.
VOLUME DAMPER, SEE VOLUME 1. SEE PLANS FOR DUCT SIZES. NOTES: W DAMPER DETAIL CINCH COLLAR LOCK WHEN THERE ARE NO FUTURE BRANCH PROVIDE VOLUME DAMPER IN MAIN DUCT TAKE-OFFS (TYPICAL). (TYPICAL). L 45° MAIN SUPPLY DUCT BRANCH DUCTWORK W, 4" MINIMUM = L 4 W MAIN RETURN DUCT 45° L
