Condensate drain trap assembly for a draw-through cooling coil connecting to the cooling coil drain pan. The pipe size matches the drain pan outlet unless indicated otherwise and runs to the nearest approved receptor. The vertical drop incorporates a tee with a cleanout typically, and unions are provided for maintenance access. Design requirements specify trap dimensions based on fan inlet static pressure plus one inch or three inches whichever is larger, or one-half fan inlet static pressure plus one inch.
1 4 3 UNION (TYP.) TEE WITH CLEANOUT (TYP.) DRAW THROUGH COIL NOTES: # 1. 2. 3. 4. 5. COOLING COIL DRAIN PAN. TO NEAREST APPROVED RECEPTOR. MATCH PIPE SIZE TO DRAIN PAN OUTLET UNLESS INDICATED OTHERWISE. FAN INLET STATIC PRESSURE PLUS 1", OR 3" WHICHEVER IS LARGER. 1/2 FAN INLET STATIC PRESSURE, OR 1" WHICHEVER IS LARGER. NONE 8 CONDENSATE DRAIN DETAIL o o OL o
