An up-blast roof exhaust fan is mounted on a curb with a one-and-a-half-inch by three-eighth-inch closed-cell neoprene self-adhesive gasket separating the fan housing from the support. The unit is secured using stainless steel truss head screws measuring number ten by one-and-a-half inches minimum and anchored with nails through the roofing and flashing installed by the general contractor. A backdraft damper is located inside the duct drop where specified. A two-inch drip pan soldered all around for watertightness is positioned at the base alongside a flexible duct connection.
SS TRUSS HEAD SCREW (#10 X 1-1/2" MIN.) NOTES: (1) CURB WILL BE PROVIDED BY GC UNLESS SPECIFIED TO BE FURNISHED WITH FAN. CURB FURNISHED WITH FAN WILL BE INSTALLED BY GC. (2) CURB DETAILS INDICATED ON THE ARCHITECTURAL DRAWINGS SUPERCEEDE THE MECHANICAL DRAWING DETAILS. 90° FLANGE OUT OF ALL SIDES. COMPLETE WITH FILLED IN CORNERS. BACKDRAFT DAMPER WHERE SPECIFIED ROOFING AND FLASHING BY GC NAIL 2" DRIP PAN SOLDERED ALL AROUND FOR WATER TIGHTNESS FLEXIBLE CONNECTION (1) 1-1/2" X 3/8" CLOSED CELL NEOPRENE SELF ADHESIVE GASKET 2" 36" MIN.
