An eight-inch deep sheet metal box connects to an insulated sheet metal elbow via a round neck secured with sheet metal screws. The interior of the box is painted flat black. The assembly is set into a gypsum board ceiling with a minimum of two sheet metal screws per side. A flexible duct of maximum five-foot length attaches to the elbow using a duct strap and a panduit fastener, with mastic applied between the elbow and flex duct. Eighteen-gauge wire seismic restraints are secured to opposite corners of the box and anchored to the ceiling support structure.
GYPSUM BOARD CEILING SHEET METAL SCREWS ROUND NECK FLEXIBLE DUCT MAX 5'-0" LENGTH PANDUIT FASTENER INSULATED SHEET METAL ELBOW APPLY MASTIC BETWEEN ELBOW AND FLEX DUCT DUCT STRAP 8" PAINT INTERIOR OF BOX FLAT BLACK SHEET METAL BOX SHEET METAL SCREWS (2 PER SIDE MIN) 18 GAUGE WIRE SEISMIC RESTRAINTS AT OPPOSITE CORNERS (SECURE TO CEILING SUPPORT STRUCTURE)
