An externally insulated takeoff connects to a pre-insulated flexible duct feeding a ceiling diffuser set flush in the ceiling plane. The takeoff features an integrated volume damper with a damper lock and extension. Foil tape seals the insulation joints, while metallic or non-metallic bands secure the duct connections. A rigid ninety-degree elbow is incorporated where required to maintain the flexible duct within the five-foot length limitation without kinking or sharp turns.
CEILING CEILING DIFFUSER AS SCHEDULED NOTES: EXTERNALLY INSULATED TAKEOFF WITH VOLUME DAMPER AND DAMPER LOCK WITH EXTENSION METALLIC OR NON-METALLIC BAND (TYPICAL) FOIL TAPE AT INSULATION JOINT PRE-INSULATED FLEXIBLE DUCT AS REQUIRED, INSTALL PERMANENTLY SEALED AND SUPPORTED TO PREVENT KINKING AND SHARP TURNS PROVIDE RIGID 90° ELBOW WHERE REQUIRED TO KEEP FLEXIBLE DUCT WITHIN 5'-0" LENGTH LIMITATION. METALLIC OR NON-METALLIC BAND OVER INSULATION (TYPICAL)
