Mechanical · M-GH29S

Heating Coil Connection Detail

Elements

About this detail

This diagram details the piping connections for heating coils tied to hot water supply and hot water return lines. The assembly incorporates isolation valves, an in-line pump with a check valve, a modulating two-way valve, and Weiss thermometer model DVS35 units typically installed at key points. Each coil connection includes typical unions, flexible connections, pressure and temperature test plugs, circuit setters, and air vents. A three-quarter-inch drain valve with a hose end and a pipe to drain are provided for maintenance.
