An inline exhaust fan is suspended from the overhead structure using all-thread rods combined with spring vibration isolators. Flexible duct connectors are installed on both the inlet and discharge sides of the fan to isolate mechanical vibration from the ductwork. Transition fittings connect the fan inlet and discharge to the indicated duct sizes.
EXHAUST FAN HANG UNIT FROM STRUCTURE WITH SPRING VIBRATION AND ALL-THREAD ROD. SEE NOTE 2. TRANSITION FROM FAN INLET TO DUCT SIZE INDICATED TRANSITION FROM FAN DISCHARGE TO DUCT SIZE INDICATED FLEX CONNECTOR
