Base-mounted pumps are supported on an inertia base equipped with vibration and seismic isolation resting on a housekeeping pad. A suction diffuser with a support leg and a wye strainer with blowdown connect to the pump suction piping. Pipe reducers and flexible mechanical couplings or braided flexible hoses are installed typically on the piping runs. A check valve is integrated into the discharge piping above the pump.
CHECK VALVE PUMP HOUSE KEEPING PAD FLOOR 1. PIPE REDUCER AS REQUIRED (TYP). 2. FLEXIBLE MECHANICAL COUPLING OR BRAIDED FLEXIBLE HOSE (TYP). 3. INERTIA BASE WITH VIBRATION ISOLATION AND SEISMIC ISOLATION PER SPECIFICATION. NOTES: 1 2 3 WYE STRAINER WITH BLOWDOWN SUCTION DIFFUSER SUPPORT LEG NONE 3 BASE MOUNTED PUMPS WITH SUCTION DIFFUSER DETAIL
